Properties

  • 0104.100LX4T23E3
  • TECHTOP
  • 5412463002005
  • 3
  • 100
  • B3
  • 4P / 1500rpm
  • 230/400V
  • TC
  • IE3
  • Cast iron

Links & downloads

Download productfiche

TECHTOP 100 LX electric motor - 3kW, 4 pole / 1500rpm, B3

0104.100LX4T23E3

400,44 €/piece 21% VAT excluded
Discover the robust reliability of our T3C electric motor, designed with a cast iron frame for durable performance in demanding environments. With a power of 3 kW and a speed of 1500rpm, this motor delivers powerful performance for a wide range of applications.

With its flexible terminal box position and sturdy construction, the T3C motor is ideal for installations where reliability is essential. Standard equipped with an IP55 rating and featuring an integrated PTC (Positive Temperature Coefficient) for additional protection and safety, this motor provides optimal performance even in challenging conditions.

Trust the T3C electric motor for consistent and durable operation, tailored to the requirements of your application.

Discover the features of our 100LX electric motor:
·Construction size: 100LX
·Motor Type: TC
·Power: 3kW
·Number of poles/Speed: 4 pole / 1500rpm
·Voltage: 230/400V
·Mounting configuration: B3
·Brand: TECHTOP
·Frame type: Cast iron
·IE class: IE3

Trust in the quality and reliability of TECHTOP for all your electric motor needs.
 Show more
